- Size: 7295*2574*3240
- Place of Origin: China
- Brand Name: SDLG
- Model Number: LG946L
- Weight: 42.000 kg
Specification:
Item | LG9 46L | Engine | Weichai Deutz Engine |
Transmission | LG A307A Planetary power shift +Forward I I /Reverse I | Bucket Capacity ( m3) | 2.5 |
Axle | SDLG+A504 | Rated Load (kg) | 4000 |
Hydraulic System | Pilot Control | Max Dumping Height (mm) | 2951 |
Working Arm | Standard | Cycle Time (s) | 10.2 |
Control Valve | 2 Valve | Min Steering Radius (mm) | 6150 |
Brake System | Dual Brake Petal | Max Breakout Force (KN) | ≥133 |
Cab | Standard | Dimension (L*W*H) (mm) | 7345 *2 790 * 3240 |
Cooling/Heating System | Air Conditioner | Operating Weight (kg) | 13130 |
Quick Coupler | No | Attachment | Reforced LM bucket |
Description:
LG938L is a high-end loader for loading and unloading loose materials, with reliability and multiple purpose, and is widely used in building site, small mining, aggregate plant and municipal construction and etc.
Advantages:
1. The entire machine uses special NVH technique of SDLG and three-stage damping system, new damping seat better damping performance, which makes it comfort to operate for driver.
2. FOPS/ROPS cab is equipped, which has wide vision, fully-covered cab internal trimmings, good sealing performance, up-to-ISO-standard air conditioning and is safe and comfortable. Common cab is optional.
3. It is equipped with the DEUTZ engine, imported with original packing from Germany, meeting the requirements.
4. It is provided with optimized front and rear frame design and reasonable load distribution. Steering soft limit is provided to reduce impact. The overall fatigue life is up to 8,000h; The hanging is a tapered roller bearing and oscillating bearing composite structure, which makes it more suitable for bad operating condition.
